INDEX NO.
|
PART NAME
|
QTY
|
|
1
|
AIR INLET NUT
|
1
|
|
2
|
SPRING CAP
|
1
|
|
3
|
VALVE BODY WASHER
|
2
|
|
4
|
SPRING FOR VALVE
|
1
|
|
5
|
WASHER LOCK(SHORT)
|
1
|
|
6
|
VALVE POPPET WASHER
|
2
|
|
7
|
VALVE BODY
|
1
|
|
8
|
O-RING FOR VALVE BODY
|
1
|
|
9
|
VALVE POPPET
|
1
|
|
10
|
WASHER LOCK(LONG)
|
1
|
|
11
|
C-PIN-1
|
1
|
|
12
|
TRIGGER LINK
|
1
|
|
13
|
TRIGGER
|
1
|
|
14
|
C-PIN-2
|
1
|
|
15
|
C-PIN-3
|
1
|
|
16
|
CYLINDER BODY
|
1
|
|
17
|
WASHER
|
2
|
|
18
|
NUT FOR PISTON ROD
|
1
|
|
19
|
OIL SEAL FOR PISTON
|
1
|
|
20
|
PISTON
|
1
|
|
21
|
CYLINDRICAL SPRING FOR PISTON
|
1
|
|
22
|
SCREW FOR CYLINDER HEAD
|
8
|
|
23
|
SPRING WASHER
|
8
|
|
24
|
CYLINDER HEAD
|
1
|
|
25
|
PISTON ROD
|
1
|
|
26
|
PIN FOR UPPER LINK
|
1
|
|
27
|
LINK
|
2
|
|
28
|
JAW LINK PIN
|
2
|
|
29
|
NOTCHER
|
2
|
|
30
|
JAW
|
4
|
|
31
|
JAW NOTCHER PIN
|
2
|
|
32
|
JAW NOTCHER SIDE PLATE PIN
|
2
|
|
33
|
SIDE PLATE NOTCHER BOLT
|
1
|
|
34
|
SIDE PLATE NOTCHER NUT
|
1
|
|
35
|
SIDE PLATE
|
2
|
|
36
|
BOLT FOR SIDE PLATE
|
2
|
|
37
|
NUT FOR SIDE PLATE
|
4
|
